Composition of Production Line

• 24 independent spin coating modules arranged in a circular or U-shaped layout

• Collaborative robot (cobot) for product transfer between modules

• Centralized coating supply and waste collection manifold

• Modular drying towers (IR, convection, or combination)

• Smart conveyor interface for inline integration

• Universal product carriers (adjustable without tools)

• Edge computer with OPC UA connectivity

• Real-time energy monitoring dashboard

Product Description

This modular 24-station robotic spin coating workcell breaks away from traditional fixed indexing turntables. Instead, 24 independent spin coating modules are arranged flexibly (circular, linear, or U-shaped), and one or two collaborative robots transfer products between modules. This design allows dynamic routing: a product can skip stations if drying is complete or revisit stations for multi-layer coating. Each spin module has its own motor, dispenser, and local controller, enabling true parallel processing with zero bottleneck. The workcell is ideal for manufacturers who frequently change product shapes or coating formulas, as the modular design allows reconfiguration in hours rather than days. Perfect for medium-volume, high-mix production of molded pulp internal coatings.

Technical Parameters

Application

• High-mix production of various molded pulp trays (fruit, egg, electronic, medical)

• Multi-layer coating: primer + barrier + topcoat without moving to another machine

• Low to medium volume (500–5000 parts/day) with frequent changeovers

• Pilot lines or R&D scale-up for new coating formulations

• Just-in-time manufacturing for customized coated pulp packaging

Customization

Every component is customizable: number of spin modules (8–48), robot brand and payload, layout geometry (customizable for existing floor space), customizable coating module – airless spray, ultrasonic spray, or needle dispense, customizable drying module types (IR wavelength, convection airflow), and customizable product carrier design (universal fingers or shape-specific nests). Also customizable software interface: MES integration, batch reporting, or mobile dashboard. Customizable safety fencing and light curtains to meet local regulations.

Feature

• Dynamic routing – any product can go to any spin module in any order

• Zero downtime reconfiguration – swap a module in <15 minutes

• Parallel processing – 24 parts coated simultaneously, not indexed

• Energy-efficient: modules power down when idle

• Built-in collision detection and force limiting (safe for manual intervention)

• Recipe-driven changeover – select product file, robot automatically adjusts gripper and spin parameters

• Open architecture – write your own control logic via REST API

Support and Services

• Free layout simulation and cycle time analysis

• On-site modular assembly and robot programming (3–5 days)

• Operator training including robot safety certification

• 12-month warranty on all modules, 24 months on robot arm

• Remote access to PLC and robot for troubleshooting

• Flexible service contract: pay-per-use or annual

Packing and Shipping

• Each spin module packed individually in foam-lined carton

• Robot and controller in original manufacturer crate

• Structural frames and conveyors in plywood crates

• Multiple pallets – can ship as air freight for urgent setups

• Delivery: FCA / DDP options

• Includes QR-code based assembly instructions (video + 3D models)

FAQ

Q: How long does it take to change from one product shape to another?
A: For a completely different product, changeover takes 10–20 minutes: robot gripper change (tool-less), spin cup insert (quick-release), and recipe selection. Customizable quick-change pallets can reduce this to 2 minutes.

Q: Can I run a small batch (e.g., 50 parts) without wasting coating material?
A: Yes – each spin module has a small reservoir (20–200 ml). The system can customizable purge and clean only the modules used. No need to fill all 24 stations.

Q: What if I need more than 24 stations in the future?
A: The modular architecture is fully customizable and expandable. Simply add more spin modules and update the robot program. The control software automatically recognizes new modules.

Q: Is this system suitable for solvent-based coatings with explosion risk?
A: Yes – we offer a customizable explosion-proof version with ATEX-certified spin modules, sealed robot, and inert gas purge.
